ZS-102C
Multichannel Power Amplifier |
ZS-202C
Multichannel Power Amplifier |
ZS-203CB
250W Dual Power Amplifier |
 |
 |
 |
- Rated Input Selection/Impedance : 10W, 5W (100V line)
- Frequency Response : 150 ~ 10.000Hz
- Sound Pressure Level (1W/1m) : 90dB
- Speaker Components : 2 units 12 cm Dynamic Speaker
- Dimensions (WxHxD) : 167x335x141 mm
- Weight : 3.4kg
- Material : Extruded Aluminum casing with punched net grille
- Color : Casing; Silver Gray, Grille : Black
- Accessories : Bracket
|
- Rated Input Selection/Impedance : 20W, 10W (100V line)
- Frequency Response : 150 ~ 10.000Hz
- Sound Pressure Level (1W/1m) : 93dB
- Speaker Components : 4 units 12 cm Dynamic Speaker
- Dimensions (WxHxD) : 167x580x141 mm
- Weight : 5.1kg
- Material : Extruded Aluminum casing with punched net grille
- Color : Casing; Silver Gray, Grille : Black
- Accessories : Bracket
|
- Type : Sealed Type
- Rated Input Selection: 20W
- Impedance : 100V line : 500Ω (20W), 1kΩ (10W), 2kΩ(5W), 4kΩ(2.5W), 70V line : 500Ω (10W), 1kΩ (5W), 2kΩ(2.5W), 4kΩ(1.3W)
- Frequency Response : 150 ~ 16.000Hz
- Sound Pressure Level (1W/1m) : 90dB
- Speaker Components : 10 cm (4”) cone type x 2
- Connector : Push-in terminal
- Dimensions (WxHxD) : 135x250x128 mm
- Weight : 1.9kg
- Material : Extruded Aluminum casing with punched net grille
- Color : HIPS, black/white
- Accessories : Punched net, speaker bracket, joint bracket, wall bracket
|
| |
|
|
ZS-203CW
250W Dual Power Amplifier |
ZS-403CB
250W Dual Power Amplifier |
ZS-403CW
Multichannel Power Amplifier |
|
 |
|
- Type : Sealed Type
- Rated Input Selection: 20W
- Impedance : 100V line : 500Ω (20W), 1kΩ (10W), 2kΩ(5W), 4kΩ(2.5W), 70V line : 500Ω (10W), 1kΩ (5W), 2kΩ(2.5W), 4kΩ(1.3W)
- Frequency Response : 150 ~ 16.000Hz
- Sound Pressure Level (1W/1m) : 90dB
- Speaker Components : 10 cm (4”) cone type x 2
- Connector : Push-in terminal
- Dimensions (WxHxD) : 135x250x128 mm
- Weight : 1.9kg
- Material : Extruded Aluminum casing with punched net grille
- Color : HIPS, black/white
- Accessories : Punched net, speaker bracket, joint bracket, wall bracket
|
- Type : Sealed Type
- Rated Input Selection: 40W
- Impedance : 100V line : 250Ω (40W), 500Ω (20W), 1kΩ(10W), 2kΩ(5W), 70V line : 250Ω (20W), 500Ω (10W), 1kΩ (5W), 2kΩ(2.5W)
- Frequency Response : 150 ~ 16.000Hz
- Sound Pressure Level (1W/1m) : 93dB
- Speaker Components : 10 cm (4”) cone type x 4
- Connector : Push-in terminal
- Dimensions (WxHxD) : 135x250x128 mm
- Weight : 3.5kg
- Material : Extruded Aluminum casing with punched net grille
- Color : HIPS, black/white
|
- Type : Sealed Type
- Rated Input Selection: 40W
- Impedance : 100V line : 250Ω (40W), 500Ω (20W), 1kΩ(10W), 2kΩ(5W), 70V line : 250Ω (20W), 500Ω (10W), 1kΩ (5W), 2kΩ(2.5W)
- Frequency Response : 150 ~ 16.000Hz
- Sound Pressure Level (1W/1m) : 93dB
- Speaker Components : 10 cm (4”) cone type x 4
- Connector : Push-in terminal
- Dimensions (WxHxD) : 135x250x128 mm
- Weight : 3.5kg
- Material : Extruded Aluminum casing with punched net grille
- Color : HIPS, black/white
|
| |
|
|
ZS-603CB
250W Dual Power Amplifier |
ZS-603CW
250W Dual Power Amplifier |
|
 |
|
|
- Type : Sealed Type
- Rated Input Selection: 60W
- Impedance : 100V line : 170Ω (60W), 330Ω (30W), 670Ω (15W), 1.3kΩ (7.5W), 70V line : 170Ω (30W), 330Ω (50W), 670Ω (7.5W), 1.3kΩ(3.8W)
- Frequency Response : 150 ~ 16.000Hz
- Sound Pressure Level (1W/1m) : 95B
- Speaker Components : 10 cm (4”) cone type x 6
- Connector : Push-in terminal
- Dimensions (WxHxD) : 135x746x128 mm
- Weight : 5.5kg
- Color : HIPS, black/white
|
- Type : Sealed Type
- Rated Input Selection: 60W
- Impedance : 100V line : 170Ω (60W), 330Ω (30W), 670Ω (15W), 1.3kΩ (7.5W), 70V line : 170Ω (30W), 330Ω (50W), 670Ω (7.5W), 1.3kΩ(3.8W)
- Frequency Response : 150 ~ 16.000Hz
- Sound Pressure Level (1W/1m) : 95B
- Speaker Components : 10 cm (4”) cone type x 6
- Connector : Push-in terminal
- Dimensions (WxHxD) : 135x746x128 mm
- Weight : 5.5kg
- Color : HIPS, black/white
|
