Spesifikasi :
- Power Requirement : 220V AC (198-242), 50/60Hz. Dry cells 8pcs (R20P or D size) external DC 10-16V
- Power Consumption : AC : 44W; DC : 1.200mA
- Rated Output : AC : 15W (Max. 20W), DC : 6W
- Frequency Response : ± 3dB (70-10.000Hz)
- Distortion : Under 3% at rated output
- Input : MIC 1,2,3 (cable mic) -54dBv 600Ω; AUX : -20dBv 600Ω
- Output : External Speaker : 8-16Ω/over 20W of rated output “Internal speaker and External speaker” or “External Speaker only” (by selectable switch)
- S/N Ratio : more than 70dB at rated output
- Antenna : Rod Antenna
- Speaker Internal : 20cm mechanical 2-way speaker
- Cassete deck :
- Reproduction system : non reverse (one way)
- Usable Tape : Normal tape
- Tape speed : 4.8cm/sec
- Wow and flutter : 0.3% Wrms
- Fast Forward.Rewind time : Approx. 100 second (C-60 type)
- Recording Method : AC bias
- MP3 Unit : USB type : 1.1 and 2.0; Capacity : Max. 32GB (FAT 16 & FAT 32) ; Format file : MP3 and WMA
- Ambient Temperature : AC : -10° ~ + 40° C ; DC : 0° ~ + 40° C
- Finish : ABS resin, light grey
- Dimension : 366(W) x 456(H) x 197(D) mm
- Weight : approx. 8.3 kg (battery included)
- Accessories :
- External speaker plug : 1x
- Fuse 500mA : 1x
- External DC plug : 1x
- Battery AAA : 2x
- Single Pole Plug : 1x
- Dust Cover : 1x
- Mic hand held/Tuner : ZM-810 / ZTU-810
ZTU-G810
- Receiving Frequency : 801.525, 806.357, 807.750, 813.975, 816.375, 821.275 MHz
- Antenna Input : 50Ω
- Local Oscillation : X’tal Control
- Output Level : 0dB
